The XTENDEXr HDMI USB KVM Over IP Extender with Audio, RS232, and IR provides remote KVM (USB keyboard, USB mouse, and HDMI monitor) access to a USB computer or HDMI source up to 330 feet over a Gigabit network using a single CAT5e/6 cable. Each ST-IPUSBH-1G consists of a local unit that connects to a computer or HDMI source, and a remote unit that connects to a monitor, mouse, keyboard, speaker, microphone, and other USB devices.
The local and remote units can be connected together for a Point-to-Point connection via CAT5e/6 cable or a Point-to-Many connection via a managed network switch.
Extend HDMI monitor, Audio, USB keyboard, and USB mouse up to 330 feet using Gigabit Ethernet
Also known as: HDMI USB KVM extender single CAT5, HDMI KVM over IP, remote digital HDMI monitor, HDMI transmitter/receiver, extend keyboard monitor mouse, high definition 1080p IR extender, HDTV video USB keyboard mouse balun
Features:
- Supports HDTV resolutions to 1080p and computer resolutions to 1920x1200 (WUXGA). ?Extend 1080p up to 330 feet in a Point-to-Point connection.
- Extend 1080p up to 660 feet in a Point-to-Point or Point-to-Many connection via a managed network switch.
- Supports USB 2.0 devices. ?Keyboard and mouse are hot-pluggable.
- Connect a mouse, keyboard, flashdrive, or HDD.
- Full Infrared Remote (IR) control of HDMI source from remote HDTV using existing source remote control.
- Load individual EDID tables from monitors.
- Support for multiple transmitters and receivers requires a managed network switch. ?Distance between transmitter and receiver can be up to 660 feet when using a managed network switch (330 feet on each side).
- Easily expandable - add receivers as you add control stations.
- Identically configure dip switches on a transmitter and multiple receivers to link them together. ?Simply press and hold the USB link button on a receiver for 3 seconds to gain USB control.
- Cascade managed network switches to extend the distance between transmitter and receiver.
- Up to 16 transmitters can be connected per individual network switch or between cascaded network switches.
- When using multiple remote units, only one unit can have USB control over the source at any time. ?Analog audio signals are transmitted via USB - a deactivated remote unit will continue to display video but does not provide analog sound or user control.
- HDMI digital audio will still pass through as it is embedded in the video signal.
- Supports 2-way RS232 commands at baud rate 115200 (control software on a PC, or other automated control system hardware such as Control4 or Crestron) to control devices attached to the matrix using RS232.
- Inexpensive CAT5e/6 cable replaces bulk video cables.
- HDCP compliant.
- Supports the DDC2B protocol.
- Compliant with the HDMI v1.2 standard.
Specifications:
- Sender Unit
- One female HDMI connector.
- One female USB Type B connector.
- One female 3.5mm port for IR emitter.
- One female DB9 connector for RS232.
- One female 1 Gbps RJ45 port for sending/receiving high definition video/audio, USB, IR, and DDC signals.
- Four dip switches for linking transmitters and receivers in a Point-to-Many connection.
Power - Local and remote unit: 100 to 240 VAC at 50 or 60 Hz via AC adapter.
- Power consumption: ST-IPUSBH-L-1G: 5W, ST-IPUSBH-R-1G: 12W
Cables - Use HD-xx-MM cable to connect an HDMI source or display (not included).
- Use DVI-HD-xx-MM cable to connect a DVI source or display (not included).
- Use USB Type A male to USB Type B male cable to connect a PC/notebook to the local unit (not included).
- Use CAT5e/6 straight through cable with TIA/EIA-568B wiring terminated with standard RJ45 connectors (not included)
Dimensions - WxDxH (in): 7.09x4.33x0.98 (180x110x25 mm).
Environmental - Operating temperature: 32 to 104°F (0 to 40°C).
- Storage temperature: -4 to 140°F (-20 to 60°C).
- Operating/storage relative humidity: 20 to 90% non-condensing RH.
Regular Approvals - CE, RoHS.
Warranty - Two years
